circuit in



1100

1200

Muscular Bio-stimulator electronic circuit diagram

Muscular Bio-Stimulator electronic circuit diagram

Warning:

The use of this device is forbidden to Pace-Maker bearers and pregnant women. Don't place the electrodes on cuts, wounds, injuries or varices. Obviously we can't claim or prove any therapeutic effectiveness for this device.


Parts:

P1______________4K7 Linear Potentiometer
R1____________180K 1/4W Resistor
R2______________1K8 1/4W Resistor (see Notes)
R3______________2K2 1/4W Resistor
R4____________100R 1/4W Resistor
C1____________100nF 63V Polyester Capacitor
C2____________100΅F 25V Electrolytic Capacitor
D1______________LED Red 5mm.
D2___________1N4007 1000V 1A Diode
Q1,Q2_________BC327 45V 800mA PNP Transistors
IC1____________7555 or TS555CN CMos Timer IC
T1_____________220V Primary, 12V Secondary 1.2VA Mains transformer (see Notes)
SW1____________SPST Switch (Ganged with P1)
B1_____________3V Battery (two 1.5V AA or AAA cells in series etc.)

Device purpose:

This is a small, portable set, designed for those aiming at look improvement. The Bio-Stimulator provides muscles' stimulation and invigoration but, mainly, it's an aid in removing cellulitis. Tape the electrodes to the skin at both ends of the chosen muscle and rotate P1 knob slowly until a light itch sensation is perceived. Each session should last about 30 - 40 minutes.

Circuit operation:

IC1 generates 150΅Sec. pulses at about 80Hz frequency. Q1 acts as a buffer and Q2 inverts the pulses' polarity and drives the Transformer. Output pulses' amplitude is set by P1 and approximately displayed by LED D1 brightness. D2 protects Q2 against high voltage peaks generated by T1 inductance during switching.

Notes:

* T1 is a small mains transformer 220 to 12V @ 100 or 150mA. It must be reverse connected i.e.: the 12V secondary winding to Q2 Collector and ground, and the 220V primary winding to output electrodes.
* Output voltage is about 60V positive and 150V negative but output current is so small that there is no electric-shock danger.
* In any case P1 should be operated by the "patient", starting with the knob fully counter-clockwise, then rotating it slowly clockwise until the LED starts to illuminate. Stop rotating the knob when a light itch sensation is perceived.
* Best knob position is usually near the center of its range.
* In some cases a greater pulse duration can be more effective in cellulitis treatment. Try changing R2 to 5K6 or 10K maximum: stronger pulses will be easily perceived and the LED will shine more brightly.
* Electrodes can be obtained by small metal plates connected to the circuit's output via usual electric wire and can be taped to the skin. In some cases, moistening them with little water has proven useful.
* SW1 should be ganged to P1 to avoid abrupt voltage peaks on the "patient's" body at switch-on, but a stand alone SPST switch works quite well, provided you remember to set P1 knob fully counter-clockwise at switch-on.
* Current drawing of this circuit is about 1mA @ 3V DC.
* Some commercial sets have four, six or eight output electrodes. To obtain this you can retain the part of the circuit comprising IC1, R1, R2, C1, C2, SW1 and B1. Other parts in the diagram (i.e. P1, R3, R4, D1, D2, Q2 & T1) can be doubled, trebled or quadrupled. Added potentiometers and R3 series resistors must be wired in parallel and all connected from Emitter of Q1 to positive supply.

Getting a good-looking date

Hello to all my readers. Welcome to the latest of the bi-weekly Public Newsletters. – At least, it’s the latest until the next one’s published.

Getting a good-looking date

The first thing I’m going to tell you in this Newsletter is why I always write the date, online, as above in the title: -

It’s all because of Americans. who make up around 1/4 to 1/3rd (0.25 to 0.34) of my readership. As you probably already know; Americans write the date differently compared to we Brits: Where an American would write the date above as

10.23.2009

Brits would write it as

23.10.2009

From the above it seems fairly obvious, provided that you are aware that they’re both the same day, that one is the date written by an American, and one is the date written by a Brit; particularly if you know that it’s the date related to an article published on 23rd October: There’s really no issue there; until it comes to a date like 08.09.2009, or 10.11.2010: One of those dates was written by an American, but which one?

- So rather than cause any confusion by writing the date as 08.09.2009; which to an American is 9th August, yet to a Brit is 8th September, I write it out so that it can be understood whichever way round you do it in your part of the world.

Surely everybody knows what month it is!” You retort.

Currently yes; but imagine you’re an American digging through archives, finding the post you’re looking for by date, loading it onto a USB stuck, driving to your next destination, and then finding that the post was written by a Brit and that you got the wrong post because you read the date in American format rather than British format.

Blog Contents Page

Next; I’ve automated the Blog Contents page: In doing so I’ve lost a number of the listings. Everything related to that is explained near the top of that page itself; but I’ll reproduce the important parts here also: -

“Previously I was hard-coding each post into the list manually. I actually devised a way of doing it fairly quickly and with little effort. – I just wasn’t happy with doing things that way though: It was something else that had to be done, costing more time, and I also didn’t always remember to do it after every post’s publication.

It is in the light of the above that I’ve configured an existing script to handle the matter of posting and updating this Blog Contents page. While the operation is almost perfect, the script is unable to handle [all the previously viewable entries in the list.] …I’ve just done the best I can for now.

…Approximately 7 months of posts are currently listed, in total. I’m seeking a solution that will allow me to list more posts: Please bear with me until that time.”

Changes to the Welcome Page

As you may have noticed, I’ve partially automated the Welcome Page by adding a display of a snippet of my latest post to the page, as well as adding a clickable listings link to any of the latest 20 posts. I’ve also amended and partially rewritten the “Objective of This Blog” text section, in addition to which I’ve made all fonts on the page Trebuchet MS, and all linked text is now standard-link-blue (0000FF hex value.).

Reduced input

As I stated in the last Public Newsletter, I might yet have to reign back on the frequency with which I post articles at some point. It’s not that I don’t like writing; it’s just that I don’t have a lot of time some days or weeks. If there’s no content added to this blog one day, don’t instantly assume that it’s died. – Anyway, I currently announce future content on the welcome Page, previous to publication, so I’ll announce any gaps too, or simply won’t announce when there’ll be no new material. – If it’s not announced then it won’t happen.

Yes I do hand-code that announcement; although if anybody knows of a plugin which will list articles scheduled for publication then I’d be most happy to know about it myself. – With WordPress there’s normally a plugin for it, whatever it is. – It’s just a matter of finding it.

I’m going to be producing a different type of content as well as free articles from this coming Monday onwards; that being paid-for premium content, which will be on sale in due course: Yes I’m beginning to step up a gear with monetising this blog. – Well something’s got to pay the rent.

As a result I’ll be unable to produce as many articles as I have recently been doing – I just don’t have an unlimited amount of time on my hands.

I can probably still produce a few per week for the forseeable future; but if you have something technical and factual that you’d like to post on this blog; be my guest, literally: Submit your prospective guest-posts in line with the contest Can Your Post Make it to The Number One Slot? You never know; you might win.

Circuit Diagrams8

Circuit Diagrams

One of the jokes from the Tek service manuals!

530,540,550,580 Series

And for all those poor souls having just found their first Tek and unsure on how to proceed, finding the poor thing dead and not having a manual, I have here some useful bits of circuit diagram. These I copied from the Tek 585A manual, but I believe them to be reasonably representative of most 530, 540 and 580 series scopes. You may wish to disagree, please let me know. Note: Tube numbers for the non-A versions are different.

  • HT power supply circuit diagram Note: Be careful with the HT!
  • Low voltage power supply circuit diagram Note: Be even more careful with the LOW voltages in your old Tek. 350 volts at >125 mA is NOT funny. ;) Your 6080 SQ will continue to regulate untill you drop dead or it does- and I'd place my bets on the 6080......
  • Calibrator circuit diagram Note: for this schematic, the tube complement may vary. For example, the 531 is equipped with a 6DJ8 and a 6U8. The circuit diagram serves to demonstrate the basic working of this circuit.

560 Series

Here is something similar for the 560 series of scopes. The diagrams are from the manual of the 564, but I suspect the 561 will be largely identical. I don't know about the 560 itself. The 564B is different.

Notes: See above.

K8 – PIC-based electronic morse keyer

K8 – PIC-based electronic morse keyer


K8 keyer as built by ON4BDS
Kindly offered to the ham community as freeware, the K8 keyer by K1EL is an iambic keyer, embedded as software in a PIC chip. Its biggest advantages are that it is free (duh!), easy to build and very small.

The best implementation I have seen so far, is from W0PWE. He has circuit diagrams, PCB layouts and much more. The original presentation of this keyer can be found at K1EL’s homepage. You will need a PIC programmer to upload the software. I have one available on my Electronics pages.

The disk with the holes you see on the front of my memory keyer is in fact a small speaker that I salvaged from a set of defective cheap headphones. I found that piezzo speakers only give moderate output at the 800Hz the PIC puts out. I must say the headphones speaker doesn’t do any better, but it’s enough because my rig puts out a sidetone as well, and I have my headphones on anyway…

I run the keyer on a pair of AA batteries, which works very well. The keyer does not need an on/off switch, since the idle current of the PIC is only a few µA’s. I haven’t had to replace the batteries for two years.

The Millipede

Me and a friend are both trying to build a millipede. Because of obvious reasons, the millipede is NOT going to have 1000 feet!!! Instead, it's going to have 16 pager motors as feet. It will also have 3 MicroMotors to ''bend'' towards light, and a backup sensor.

FEATURES:
16 PagerMotors as feet
3 MicroMotors to seek light
PhotoTrophic
Obstacle avoidance
Looks Cool!!!

MECHANICS:

Millipede is divided in four segments. Each segment (except the first one) is glued to a MicroMotor turned upside-down. The motor shaft is then glued to the next segment. Each segment can rotate left/right and has 2 PagerMotors on each side. This way, the millipede should turn towards the most lighted area. I've calculated that the waist motors should turn only 30o-45o every second or so. This means that I will need the motors to be 7-15 rpm. Candidates for this job can be the Lego MicroMotor (http://costaricabeam.solarbotics.net/Info/Lego%20MicroMotor.htm), Solarbotics GM or BabyGM (unless I can get some MU915L Escaps!!!).
Weigth was a major concern since the whole bot was impulsed by pagermotors. The waist motors should weigth no more than 70g and the body (including electronics) is about <100g.>

ELECTRONICS:

Circuit diagram

I made up this circuit, as this is my first ''big'' BEAM creation I have no idea if it works properly. The upper 3 Ms are the Lego MicroMotors and the lower Ms should be the 16 PagerMotors. On the right, you can see the MicroMotors driver.

Here is the explanation:
1 This is the voltage divider. It divides voltage depending on which side is more iluminated, then, the schmitt changes the signal from a wave to a straight pulse.
2 The (usual) Nv only works when the input receives a HIGH, and that is the job of the schmitts. If the first schmitt outputs a HIGH the the lower strip of Nvs will work, the upper strip should stay calm because the second schmitt inverts the signal to a LOW. Thanks Math!!!
3 I can now be sure that there won't be 2 pulses on a same motor, and that when the first motor turns left (or right) the next one will also turn that same way, and the next and the next.... Only the first motor is affected by light, the others follow (in a wave pattern) the one before themselves. Since the millipede is moving forward while all this happens, a nice wave should appear when the bot has locked his path towards the light source.
4 This is the backup switch. When the bot bumps into something like... Hmm....anything, the cap is discharged trough the right schmitt. The (now LOW) output of the schmitt will reverse the PagerMotors, thus, reversing the whole bot.
5 This is the PagerMotors driver. I took the 4 transistor circuit design and modified it to be used with only one input signal. I know I won't be able to drive the 16 motors with 2N390X transistors, I used them in the schematic only because I need to find more powerful ones. Probably FETs?
6 As an extra (Yupeee), when the bot reverses it also makes the ''spinal column'' think that light is fully comming only from one direction. Because of this, when the millipede reverses, it also turns to one side all the body.

I still need to order the components (Let's just say there are not many 74**14s or 240s in Costa Rica), so the final version may be different than the drawings. I'm also thinking about using the Baby GMs that Solarbotics sell instead of the Lego MicroMotors. If you can help me with anything about the schematic, just email me.

A circuit diagram

ConceptDraw PRO
Discover the World of Visual Communication©

Wiring Diagrams with ConceptDraw PRO

A wiring diagram is a comprehensive diagram of each electrical circuit system showing all the connectors, wiring, terminal boards, signal connections (buses) between the devices and electrical or electronic components of the circuit. It also identifies the wires by wire numbers or colour coding. Wiring diagrams are necessary to troubleshoot and fix electrical or electronic circuits.

Wiring Diagram

A circuit diagram makes use of standardized symbols that represent electrical components or devices. It is easier to draw these symbols than drawing the concrete pictures of the components.

Wiring Diagram

The actual components might change appearance as the electronics industry revises them or renders them obsolete. The diagrams describe the way in which the components are connected electrically. There are drawn lines that stand for wires or conductors between the appropriate connection points on the symbols; no particular type of wire or physical distance between components is implied; two components might be separated by a few inches or centimeters or a meter or feet.

HOW TO READ CIRCUIT DIAGRAMS

introHOW TO READ CIRCUIT DIAGRAMS

this instructable will show you exactly how to read all those confusing circuit diagrams and then how to assemble the circuits on a breadboard!

for all the electronics hobbyist wannabes this is a MUST-READ instructable.

knowing how to read circuits is a very useful skill that will help you out all the time. especially if you start messing around with building little electronics projects.

In addition to reading this instructable it may be a good idea for you to read my other instructable "electronics components and what they do" to get a good understanding of what you are doing when building a project. (woops not done with this yet, i got caught up with other stuff, check back in a week or so)

Z80



The purpose of this page and its sub pages about members of Z80 family (and close relatives) is to collect and share information and good ideas. I know there are lots of people out there, who have developed some good utilities and hardware solutions. Now we all can share this infomation.
This page contain docs, FAQs, source code, (cross-)assemblers, (cross-)compilers, utilities, etc. as well as links to other Z80 relevant stuff.
Some of the info found here is property of Zilog, like hardware docs, instruction sets, and some of the software available. Read the copyright notice.
If you know an URL matching the subject of this WWW-page, tell me, and give recommendations where to place best.
Some of the links here are no more online and some are not yet correct: they are marked with a ??? sequence; in case you know the appropriate URL: I'm ready for an update.
Please report all updates, corrections and suggestions to the webmaster Gaby Chaudry.
Be aware of the fact that many products mentioned in this series of Z80 related documents are nowadays out of production: if you want to start a project, don't forget to check where to get the parts from, and what the conditions are ...

Emergency Light Circuit Diagram

Emergency Light Circuit Diagram


The circuit of automatic emergency light presented here has the following features: 1. When the mains supply (230V AC) is available, it charges a 12V battery up to 13.5V and then the battery is disconnected from the charging section. 2. When the battery discharges up to 10.2V, it is disconnected from the load and the charging process is resumed. 3. If the mains voltage is available and there is darkness in the room, load (bulb or tube) is turned on by taking power from the mains; otherwise the battery is connected to the load. 4. When the battery discharges up to 10.2V and if the mains is not yet available, the battery is completely disconnected from the circuit to avoid its further discharge. The mains supply of 230V AC is stepped down to 18V AC (RMS) using a 230V AC primary to 0-18V AC, 2A secondary transformer (X1), generally used in 36cm B&W TVs. Diodes D1 through D4 form bridge rectifier and capacitor C5 filters the voltage, providing about 25V DC at the output. Charging section includes 33-ohm, 10-watt resistor R2 which limits the charging current to about 425 mA when battery voltage is about 10.2V, or to 325 mA when battery voltage is about 13.5V. When the battery charges to 13.5V (as set by VR2), zener diode D17 goes into breakdown region, thereby triggering triac TR1. Now, since DC is passing through the triac, it remains continuously ‘on’ even if the gate current is reduced to zero (by disconnecting the gate terminal). Once the battery is fully charged, charging section is cut-off from the battery due to energisation of relay RL2. This relay remains ‘on’ even if the power fails because of connection to the battery via diode D10. S4, a normally closed switch, is included to manually restart the charging process if required. Battery disconnect and charging restart section comprises an NE555 timer (IC2) wired in monostable mode. When the battery voltage is above 10.2V (as indicated by red LED D15), zener diode (D16) remains in the breakdown region, making the trigger pin 2 of IC2 high, thereby maintaining output pin 3 in low voltage state. Thus, relay RL3 is ‘on’ and relay RL4 is ‘off.’ But as soon as the battery voltage falls to about 10.2V (as set by preset VR1), zener diode D16 comes out of conduction, making pin 2 low and pin 3 high to turn ‘on’ relay RL4 and orange LED D13. This also switches off relay RL3 and LED D15. Now, if the mains is available, charging restarts due to de-energisation of relay RL2 because when relay RL4 is ‘on,’ it breaks the circuit of relay RL2 and triac TR1. But if the mains supply is not present, both relays RL3 and RL1 de-energise, disconnecting the battery from the remaining circuit. Thus when battery voltage falls to 10.2 volts, its further discharge is eliminated. But as soon as the mains supply resumes, it energises relay RL1, thereby connecting the battery again to the circuit. Light sensor section also makes use of a 555 timer IC in the monostable mode. As long as normal light is falling on LDR1, its resistance is comparatively low. As a result pin 2 of IC3 is held near Vcc and its output at pin 3 is at low level. In darkness, LDR resistance is very high, which causes pin 2 of IC3 to fall to near ground potential and thus trigger it. As a consequence, output pin 3 goes high during the monostable pulse period, forward biasing transistor T3 which goes into saturation, energising relay RL5. With auto/bypass switch S2 off (in auto mode), the load gets connected to supply via switch S3. If desired, the load may be switched during the day-time by flipping switch S2 to ‘on’ position (manual). Preset VR3 is the sensitivity control used for setting threshold light level at which the load is to be automatically switched on/off. Capacitors with the relays ensure that there is no chattering of the relays. When the mains is present, diode D8 couples the input voltage to regulator IC1 whereas diode D10 feeds the input voltage to it (from battery) in absense of mains supply. Diode D5 connects the load to the power supply section via resistor R5 when mains is available (diode D18 does not conduct). However, when mains power fails, the situation reverses and diode D18 conducts while diode D5 does not conduct. . The load can be any bulb of 12 volts with a maximum current rating of 2 amperes (24 watts). Resistor R5 is supposed to drop approximately 12 volts when the load current flows through it during mains availability . Hence power dissipated in it would almost be equal to the load power. It is therefore desirable to replace R5 with a bulb of similar voltage and wattage as the load so that during mains availability we have more (double) light than when the load is fed from the battery. For setting presets VR1 and VR2, just take out (desolder one end) diodes D7, D10 and D18. Connect a variable source of power supply in place of battery. Set preset VR1 so that battery-high LED D15 is just off at 10.2V of the variable source. Increase the potential of the variable source and observe the shift from LO BAT LED D13 to D15. Now make the voltage of the source 13.5V and set preset VR2 so that relay RL2 just energises. Then decrease the voltage slowly and observe that relay RL2 does not de-energise above 10.2V. At 10.2V, LED D15 should be off and relay RL2 should de-energise while LED D13 should light up. Preset VR3 can be adjusted during evening hours so that the load is ‘on’ during the desired light conditions

Emergency Light Circuit Diagram

Circuit diagram for emergency light which automatically switches on when power supply fails and automatically shuts down when power supply resumes


18W Audio Amplifier

circuit diagram

Amplifier parts:
P1 = 22K Log.Potentiometer (Dual-gang for stereo)
R1 = 1K 1/4W Resistor
R2 = 4K7 1/4W Resistor
R3 = 100R 1/4W Resistor
R4 = 4K7 1/4W Resistor
R5 = 82K 1/4W Resistor
R6 = 10R 1/2W Resistor
R7 = R22 4W Resistor (wire wound)
R8 = 1K 1/2W Trimmer Cermet (optional)
C1 = 470nF 63V Polyester Capacitor
C2,C5 = 100uF 3V Tantalum bead Capacitors
C3,C4 = 470uF 25V Electrolytic Capacitors
C6 = 100nF 63V Polyester Capacitor
D1 = 1N4148 75V 150mA Diode
IC1 = TLE2141C Low noise,high voltage,high slew-rate Op-amp
Q1 = BC182 50V 100mA NPN Transistor
Q2 = BC212 50V 100mA PNP Transistor
Q3 = TIP42A 60V 6A PNP Transistor
Q4 = TIP41A 60V 6A NPN Transistor
J1 RCA audio input socket

Power supply parts:
R9 = 2K2 1/4W Resistor
C7,C8 = 4700uF 25V Electrolytic Capacitors
D2 100V 4A Diode bridge
D3 5mm. Red LED
T1 220V Primary, 15 + 15V Secondary 50VA Mains transformer
PL1 Male Mains plug
SW1 SPST Mains switch

Notes:
Can be directly connected to CD players, tuners and tape recorders.
Don't exceed 23 + 23V supply.
Q3 and Q4 must be mounted on heat sink.
D1 must be in thermal contact with Q1.
Quiescent current (best measured with an Avo-meter in series with Q3 Emitter) is not critical.
Adjust R3 to read a current between 20 to 30 mA with no input signal.
To facilitate current setting add R8 (optional).
A correct grounding is very important to eliminate hum and ground loops. Connect in the same point the ground sides of J1, P1, C2, C3 &C4. Connect C6 at the output ground.
Then connect separately the input and output grounds at the power supply ground.

Technical data:
Output power: 18 Watt RMS @ 8 Ohm (1KHz sine wave)
Sensitivity: 150mV input for 18W output
Frequency response: 30Hz to 20KHz -1dB
Total harmonic distortion @ 1KHz: 0.1W 0.02% 1W 0.01% 5W 0.01% 10W 0.03%
Total harmonic distortion @10KHz: 0.1W 0.04% 1W 0.05% 5W 0.06% 10W 0.15%
Unconditionally stable on capacitive loads


desing1

new design

this is a new design of a tutorial board based on the popular PIC16F84A microcontroller. It features eight single leds, a 7-segment display, an LCD display and five push buttons. It is an ideal solution for the beginner to take his/her first programming steps in the world of microcontrollers. Having an in-circuit-programming (ICP) header, it can be easily reprogrammed without unplugging the microcontroller each time, provided that the programmer also supports this feature (like OziPic’er).

Circuit diagram

Connections
PIC16F84A......................Feature
RA0................................JP2 - S3 – JP4
RA1................................JP2 - S4 – JP4
RA2................................JP2 - S5 - JP4
RA3................................JP2 - S6 - JP4
RA4................................JP2 - JP4

PIC16F84A.......................Feature
RB0.........................JP2 – LED1 – 7 Seg (dp) – S7 Debounce - Buzzer
RB1.........................JP2 – LED2– 7 Seg (a) – LCD RS
RB2.........................JP2 – LED3– 7 Seg (b) – LCD R/W
RB3.........................JP2 – LED4– 7 Seg (c) – LCD E
RB4.........................JP2 – LED5– 7 Seg (d) – LCD DB4
RB5.........................JP2 – LED6– 7 Seg (e) – LCD DB5
RB6.........................JP2 – LED7– 7 Seg (f) – LCD DB6
RB7.........................JP2 – LED8– 7 Seg (g) – LCD DB7

Feature Description
- S1 switches the board on and off. When on, the indicator led LED9 is lit.
- S2 resets the microcontroller.
- S8 switches the LCD display on and off
- S9 switches the eight individual leds AND the 7-segment display on and off.
- Push buttons S3 to S6 correspond to RA0-RA3 inputs. They are enabled or disabled by the SW2 dip switch.
- The SW1 dip switch enables or disables the following features :
1. Connects RB0 (used as output) to LED1.
2. Connects RB0 (used as interrupt input) to S7.
3. Enables the debouncing circuit for interrupt switch S7.
4. Connects RB0 (used as output) to the buzzer.
This dip switch must be either 1000 or 0100 or 0110 or 0001.
- The 7-segment display is always connected to the individual leds. Its seven segments correspond to LED2 to LED8 (RB1 to RB7) and the decimal dot to LED1 (RB0). This correspondence enables the 7-segment display to work together with the interrupt switch S7, which is connected to RB0.
- JP4 is an 6-screw external input connector for RA0-RA4. When used, the corresponding input switches S3-S6 must be turned off by SW2. Last screw is ground.
- JP2 is a 14 pin test terminal. A voltmeter or logic analyzer can be connected any time to monitor the signal traffic in the circuit. Last pin is ground.
- JP1 is the ICP header. When in-circuit-programming is performed, the board must be OFF (by S1), as well as the LCD (by S8) and leds (by S9).
- JP3 is a 14-pin connector for the LCD module. Contrast can be adjusted by trimmer R21.
- The board can be powered either by a 9V battery or a 6-12 V power supply.
PDF versions of the schematic and PCB are included. The board has been sucessfully build and it is depicted on the following
photos :


The top photo shows the in-circuit-programming procedure with the help of an appropriate programmer (like OziPic'er) which features an ICP header. In order for the procedure to work correctly, the LCD module has to be disconnected from its socket during programming.
